货号 | 单位 | 10V01201 | 10V01202 | 10V01203 | 10V01204 | |
额定载重 | (kg) | 1000 | 2000 | 3000 | 5000 | |
测试载荷 | (kg) | 2000 | 4000 | 6000 | 10000 | |
钢钳开口 | (mm) | 0-22 | 0-30 | 0-35 | 5-45 | |
尺寸 | A | (mm) | 24 | 35 | 40 | 50 |
B | (mm) | 36 | 45 | 50 | 58 | |
C | (mm) | 155 | 155 | 175 | 218 | |
D | (mm) | 50 | 60 | 60 | 65 | |
E | (mm) | 24 | 30 | 35 | 42 | |
F | (mm) | 220-260 | 250-295 | 296-360 | 350-420 | |
G | (mm) | 30 | 38 | 40 | 60 | |
H | (mm) | 156 | 190 | 226 | 270 | |
I | (mm) | 52 | 60 | 68 | 76 | |
J | (mm) | 14 | 18 | 20 | 22 | |
净重 | (kg) | 3.6 | 6 | 9.2 | 16.5 |
